Inert ceramic ball

Inert ceramic ball

(1) Description:

Inert ceramic balls have the advantages of high strength, high stabilities to chemical and thermal circumstances. It can resist the corrosion to acid, alkali, salt and all organic solvents. Being used as a supporting and a covering materia of catalyst in reactors, oil refinery, chemical, fertilizer production, natural gas and environmental protection industries. The main role of these ceramic balls is to increase the distribution spots of gas or liquid, and to support and protect the activating catalyst with low strength.


(2)  Technical Specification

 TypeFeldsparFeldspar-MulliteMulliteMullite-CorundumCorundum
  Item
Chemical composition%Al2O320-3030-4545-7070-90≥90
Al2O3+SiO2≥90
Fe2O3≤1
Water absorption, %≤5
Acid resistance , %≥98
Alkali resistance,%≥80≥82≥85≥90≥95
Thermal resistance,℃≥1300≥1400≥1500≥1600≥1700
Crushing strength
N/grain
Φ3≥120≥140≥150≥160≥200
Φ6≥400≥420≥440≥480≥500
Φ8≥480≥520≥600≥620≥650
Φ10≥600≥700≥800≥900≥1000
Φ13≥1000≥1100≥1300≥1500≥1800
Φ16≥1500≥1600≥1800≥2300≥2600
Φ20≥1800≥2000≥2300≥2800≥3200
Φ25≥2500≥2800≥3200≥3600≥4000
Φ30≥3000≥3200≥3500≥4000≥4500
Φ38≥4000≥4500≥5000≥5500≥6000
Φ50≥6000≥6500≥7000≥8500≥10000
Φ75≥10000≥11000≥12000≥14000≥15000
Bulk density, kg/m31300-14001400-15001500-16001600-1800≥1800
Note: The data of bulk density is given for reference only, not as the acceptance criterion.

(3 Size

 Diameter, Φ368101316202530385075
 Tolerance,mm±1.0±1.5±2.0±3.0

(4) Product Standard
Chemical Industry Standard HG/T3683.1-2000 <Industrial Ceramic Ball – Inert Ceramics ball
