Intalox Saddles

Intalox Saddles

IntaloxSaddles is the opening packing with the structure of groove hemicycle, which reduce the cover between the packing and enlarge the space, therefore,the availability of the mass transfer surface will be enhanced efficiently, and it has favorable liquid distributing capability. Saddles are used in two main fields but have different properties depending on the application. One field is the chemical and petrochemical industries and another is in environmental areas such as RTO equipment

Technical Indexes of Plastic Intalox Ring


Name
Normal
mm

Diameter×Height×Thickness
mm

Surface area
m2/m3

Void space
%

Bulk density
kg/m3

No.elements
per/m3

Packing factor
m-1
Plastic
Intalox saddles
Φ2525×13×1.22888510297680467
Φ3838×19×1.2265959125200309
Φ5050×25×1.525096759400282
Φ7676×38×3.020097593700220
