Cascade Ring
Description
cascade ring is widely used in the packing towers in petroleum industry, chemical industry, alkali-Chloride industry and so on. It can reduce the resistance of gas increase the intensity of packing,also increase gas-liquid contact area.
Application:
Desulfurization of amine,Synthesis of amine decarbonization,common decompression,such as Methanol separation,Separation of organic acids and so on
it is widely used in the packing towers in petroleum industry, chemical industry, alkali-Chloride industry, coal gas industry and environmental protection, etc.
| Name | Normal mm | Diameter×Height×Thickness mm | Surface area m2/m3 | Void space % | Bulk density kg/m3 | No.elements per/m3 | Packing factor m-1 |
Cascade ring | Φ25 | 25×12.5×0.5 | 221 | 95 | 383 | 98120 | 257 |
| Φ38 | 38×19×0.6 | 153 | 96 | 325 | 30040 | 173 | |
| Φ50 | 50×25×0.8 | 109 | 96 | 308 | 12340 | 123 | |
| Φ76 | 76×38×1.2 | 72 | 96 | 306 | 3540 | 81 |
